Description
Edge+ Hygiene
With NSF certification and IP66 accreditation, the E series ensures maximum hygiene and sanitary safety.
Edge+ Mobility
The compact design, which is 2/3 smaller than standard cobots, makes the E-Series easy to transport and install anywhere.
Edge+ Return on Investment (ROI)
The E-Series is a cost-effective automation solution that provides a quick return on investment – in as little as 14 months in coffee applications.
Versatility, efficiency and precision at work
Frying
Easily fries food in oil at 170°C (224°F).
Coffee
It prepares up to three cups of espresso in 15 seconds by pouring water into the dripper like a barista.
Pasta
It cooks and prepares a variety of noodle dishes such as rice noodles and udon, maintaining consistent quality.
Ice cream
It scoops ice cream and serves it directly to customers.
Beer
It pours beer from a keg and delivers it to the pick-up area.
Learn about the technical parameters
| E0509 | |
| Lifting capacity | 5 kg |
| Range | 900 mm |
| Weight | 22.5 kg |
| Performance | |
| Tool speed | > 1m/s |
| Repeatability | ±0.05 mm |
| Operating temperature | 0-45°C |
| Power consumption | 210 W |
| Joint movements (range | max. speed) | |
| J1 | ±360 ° I 120 °/s |
| J2 | ±360° I 120 °/s |
| J3 | ±155 ° I 150 °/s |
| J4 | ±360 ° I 225 °/s |
| J5 | ±360 ° I 225 °/s |
| J6 | ±360 ° I 225°/sec. |
| Other features | |
| Mounting | Any position |
| Degree of protection | IP 66 |
| Flange interface | 2xDI, 2xDO, RS-485 |
| Force and torque measurement | Monitoring of current values in drives |
